Surfboard Leaderboard

Project writing on physics-informed design for retro arcade aesthetics.

Chris Nagel · January 2026

Idea

A retro arcade-styled surfboard leaderboard inspired by Hotline Miami. Rather than applying effects arbitrarily, I wanted each visual choice to be grounded in how CRT displays and analog recording actually work.

Components

The approach: simulate the full signal chain from light emission to human perception.

Phosphor Emission → CRT Hardware → Camera Lens → VHS Recording → Observer

The Optical Chain

Effect Physics Implementation
Voltage Sag High voltage drops under load, expanding raster and dimming image Scale and brightness modulation tied to glow pulse
Convergence Error RGB electron guns drift out of alignment at screen edges Per-channel text-shadow offsets, magnitude tied to screen position
Beam Landing Error Electrons hit wrong phosphors at corners, causing color tints Radial gradients at corners with color blend mode
Phosphor Glow Electron beam excites phosphor coating, creating bloom Layered text-shadow with pulsing spread
CRT Flicker 60Hz refresh cycle with exponential phosphor decay Full-screen overlay with time-based opacity modulation
Scanlines + Slot Mask Shadow mask creates gaps between phosphor triads CSS gradients with multiply blend mode
RGB Phosphor Triads Subpixel color pattern (inverse intensity with bloom) Vertical RGB stripes with screen blend mode
Interlace Alternating odd/even scanline fields Repeating gradient dims every other line
Chromatic Aberration Camera lens disperses light into RGB fringing Dual text-shadow (red left, cyan right), intensity tied to glow
VHS Glitch Tape-head misalignment and magnetic dropout cause tracking errors Horizontal displacement on timed cycles
Harmonic Sway Layered simple harmonic waves create an intoxicated effect Multi-frequency sine waves for translation and rotation

Research

Electron Beam

Effects that occur before light is emitted—beam energy, alignment, and landing.

Voltage Sag

CRT high voltage supplies aren't perfectly regulated. Bright content draws more current, which causes the HV to drop slightly. Lower voltage means slower electrons, and slower electrons deflect more in the magnetic field. The result: the raster expands and dims on bright scenes. VOGONS

Convergence Error

Distinct from chromatic aberration. CA is lens optics—uniform across the frame. Convergence error is CRT hardware—the three electron guns physically misalign, especially at screen edges where deflection angles are greatest. Both create RGB separation, but from different causes and with different spatial patterns. CRT-Royale

Beam Landing and Color Purity

Electron beams must hit their precise phosphor color. At screen edges and corners, deflection errors cause beams to land on adjacent phosphors. The shadow mask can also warp from heat at the center. The result is position-dependent color contamination: purple or yellow tints at corners, slight desaturation at edges. CRT-Royale

Phosphor Response

Light emission and decay after electrons hit the screen.

Phosphor Glow

CRT phosphors are excited by the electron beam, emitting photons as electrons return to lower energy states. At high brightness, phosphor strips physically grow taller, bleeding into adjacent dark areas. The perceived halo around bright elements comes from three sources: light scattering in atmosphere, diffraction in the eye's lens, and veiling glare in camera optics. LearnOpenGL

Phosphor Decay and Flicker

CRT phosphors flash when hit by the electron beam, then decay exponentially until the next refresh. This creates visible flicker, especially in peripheral vision. The P22 phosphor used in most consumer CRTs had medium persistence—fast enough for motion, slow enough to reduce flicker harshness. Unlike modern strobe/BFI, CRT flicker is a rolling scan. The gradual decay feels softer than a hard on/off cycle. Blur Busters

Inverse Intensity

When phosphor glow is at its brightest, the bloom fills the gaps between phosphor triads, making the subpixel pattern less visible. The phosphor overlay opacity decreases as glow increases. CRT-Royale

Screen Structure

Physical patterns from the shadow mask and phosphor layout.

Scanlines

CRT displays draw images by scanning an electron beam across the screen line by line. With 240p content, only half the screen lines are illuminated per frame, leaving visible gaps. Physical gaps also exist between horizontal rows of phosphor material on the shadow mask. MiSTer FPGA JRank

Interlace

Standard-definition CRTs display interlaced video: odd lines in one field, even lines in the next, at 60 fields per second. This creates 30fps full frames from 60 fields. Fine horizontal details shimmer as alternating lines refresh. libretro

Recording

Artifacts introduced by camera optics and magnetic tape.

Chromatic Aberration

Different wavelengths bend at different angles through glass. Blue light (~450nm) bends more than red (~650nm) because refractive index decreases with wavelength. This creates color fringing at high-contrast edges. Two types exist: longitudinal (colors focus at different distances) and transverse (colors focus at different positions in the focal plane). Wikipedia HyperPhysics

VHS Artifacts

VHS stores data magnetically. Physical wear causes dropout and noise. Misalignment between tape and playback head causes horizontal displacement (tracking errors). Chroma subsampling and analog signal limitations cause colors to smear horizontally. Loss of horizontal sync signal causes lines to jump or tear. Harry Alisavakis AV Artifact Atlas

Perception

How the observer experiences the combined effects.

Harmonic Motion

Objects on springs or pendulums oscillate following sine/cosine curves. Multiple frequencies with phase offsets create organic, non-repetitive motion. Degraded visuals trigger specific neural responses—the Ganzfeld effect amplifies neural noise when deprived of clear signals; top-down processing causes the brain to rely more on expectations. Combining subtle effects overwhelms normal perceptual processing, creating dreamlike states. NIH PMC Wikipedia

Rendering

Technical implementation details.

Blend Modes

Each blend mode has specific physics:

Implementation

Architecture

The leaderboard runs a ~60fps animation loop via setInterval. Effect functions take the current time and return CSS properties—text-shadow, transform, filter—which are applied inline. Static data and styles live outside the React component to prevent recreation on each render. Full-window overlay divs handle screen-wide effects like scanlines, phosphors, and flicker.

Electron Beam Effects

These happen before light is emitted—affecting beam energy, alignment, and where electrons land.

Voltage Sag

Applied to the entire board container as transform: scale() and filter: brightness(). Tied to the same glow pulse as text effects so brighter content causes more sag. A slower secondary oscillation adds the irregular "hunting" of a real power supply.

const getVoltageSag = (time) => {
  const bloomPulse = Math.sin(time * 3);
  const slowDrift = Math.sin(time * 0.15) * 0.3;
  const sagLevel = 0.65 + bloomPulse * 0.35 + slowDrift * 0.1;
  return {
    transform: `scale(${1 + sagLevel * 0.0015})`,
    filter: `brightness(${1 - sagLevel * 0.008})`
  };
};

Convergence Error

Returns per-channel RGB offsets that get applied as additional text-shadow layers. Each text element passes its normalized screen position (-1 to 1), so elements near edges and corners get more separation. Green stays centered as reference; red and blue drift opposite directions.

const getConvergenceError = (time, normalizedX, normalizedY) => {
  const edgeFactor = Math.sqrt(normX² + normY²);
  const thermalDrift = Math.sin(time * 0.0275) * 0.825;
  return {
    r: { x: staticR.x + dynamicR.x + thermalDrift, y: ... },
    g: { x: 0, y: 0 },
    b: { x: staticB.x + dynamicB.x - thermalDrift, y: ... }
  };
};

Beam Landing Error

A full-screen overlay with radial gradients at each corner (purple and yellow tints) plus a center gradient that shifts with thermal drift. Applied with mix-blend-mode: color so it tints without affecting luminance.

Phosphor Effects

These simulate light emission and decay after electrons hit the screen.

Phosphor Glow

Implemented as layered text-shadow on all text elements. White core, orange bloom layers at increasing radii. Spread values pulse with Math.sin(time * 3). Chromatic aberration shadows (red left, cyan right) are added to the same text-shadow string.

CRT Flicker

A full-screen black overlay with opacity modulated by an exponential decay curve. The decay resets 60 times per second, matching CRT refresh. Low persistence (0.4) makes the flicker visible; intensity is kept to 3% to avoid distraction.

const getCRTFlicker = (time) => {
  const cyclePosition = (time * 60) % 1;
  const decay = Math.pow(0.4, cyclePosition * 8);
  return { brightness: 1 - (1 - decay) * 0.03 };
};

Screen Structure Effects

Physical patterns from the shadow mask and phosphor layout.

Scanlines + Slot Mask

CSS repeating gradients create horizontal gaps (scanlines) and vertical gaps (slot mask). Applied with multiply blend mode so they darken without affecting colors.

RGB Phosphor Triads

Vertical red-green-blue stripes at 2px repeat. Applied with screen blend mode to simulate additive light. Opacity pulses inversely with glow—brighter bloom fills the gaps, making triads less visible.

Interlace

A static repeating gradient that dims every other line. We tested animated field alternation but it created unwanted jitter at our frame rate.

Recording and Perception Effects

Artifacts from camera recording and the observer's state.

VHS Tracking Bar

A horizontal gradient band that slowly drifts up and down the screen, simulating the bright bar visible when filming a CRT.

VHS Glitch

Applied per-row as transform: translateX(). Deterministic timing based on row index creates the appearance of tracking errors without true randomness.

Harmonic Sway

Per-row translation and rotation using sine waves at different frequencies (1.2, 0.8, 0.6 Hz) with phase offsets based on row index. Creates organic, non-repetitive motion.

Overlay Stack

Full-screen overlays are layered by z-index. Blend modes determine how each interacts with content below.

z-index Overlay Blend Mode
10Scanlines + Slot Maskmultiply
10Interlacemultiply
11RGB Phosphor Triadsscreen
11VHS Tracking Barnormal
12Beam Landing Errorcolor
12CRT Flickermultiply

Tuning

Most values went through several rounds of adjustment. The process: set to extreme to see what the effect actually does, then dial back until it's felt but not seen.

Final Values

Electron Beam

Phosphor Response

Screen Structure

Learnings

Animation

Rendering

System Design
